X06: Xilinhot Fenced steppe
General site details
| Site name | Xilinhot Fenced steppe |
|---|---|
| AsiaFlux site code | X06 |
| Location | Xilinhot, Inner Mongolia, China |
| Position | 116º 40' 17'' E, 43º 32' 45'' N |
| Elevation | 1250 m above sea level |
| Slope | 10-20 deg |
| Terrain type | Softly sloping plain |
| Area | About 50 ha |
| Fetch | 200-400 m |
| Climate | Temperate continental climate |
| Mean annual air temperature | 2 deg C (long term) |
| Mean annual precipitation | 360 mm (long term) |
| Vegetation type | Fenced steppe |
| Dominant Species (Overstory) | Stipa grandis, Leymus chinensis |
| Dominant Species (Understory) | - |
| Canopy height | About 0.5 m |
| Age | - |
| LAI | 0.26 (2006) |
| Soil type | Chestnut soil |
Observation
Eddy Covariance method (CO2)
| System | Open-path system (CO2 flux, latent heat flux) |
|---|---|
| Wind speed | Three dimensional sonic anemometer (CSAT3, Campbell scientific, USA) |
| Air temperature | Three dimensional sonic anemometer (CSAT3, Campbell scientific, USA) |
| Water vapor | Open-path analyzer (LI-7500, LI-COR, USA) |
| CO2 | Open-path analyzer (LI-7500, LI-COR, USA) |
| Measurement height | 3.5 m |
| Sampling frequency | 10 Hz |
| Averaging time | 30 min |
| Data logger | CR5000 (Campbell, USA) |
| Data storage | 2G CF card for about one month |
| Original data | Raw data |
Meteorology
| Observation items | Levels/Depth | Instrument |
|---|---|---|
| Global solar radiation(incoming) | 1.5 m | CNR1 (Kipp & Zonen, The Netherlands) |
| Global solar radiation (outgoing) | 1.5 m | CNR1 (Kipp & Zonen, The Netherlands) |
| Long-wave radiation(incoming) | 1.5 m | CNR1 (Kipp & Zonen, The Netherlands) |
| Long-wave radiation(outgoing) | 1.5 m | CNR1 (Kipp & Zonen, The Netherlands) |
| Net radiation | 1.5 m | CNR1 (Kipp & Zonen, The Netherlands) |
| PPFD (incoming) | 4 m | Li190SB,Li-Cor Inc., Lincoln, NE, USA |
| Air temperature | 1, 2, 4 m | HMP45C, VAISALA, Finland |
| Humidity | 1, 2, 4 m | HMP45C, VAISALA, Finland |
| Soil temperature | 5, 10, 20 cm | Model 107, Campbell Scientific Inc., Logan, UT, USA |
| Soil heat flux | 2 cm | HFT-3, Campbell Scientific Inc., Logan, UT, USA |
| Soil water content | 0 -10 cm | CS616, Campbell Scientific Inc., Logan, UT, USA |
| Wind speed | 3.5 m | CSAT-3, Campbell Scientific Inc., Logan, UT, USA |
| Wind direction | 3.5 m | CSAT-3, Campbell Scientific Inc., Logan, UT, USA |
| Precipitation | 4 m | TE525, Texas Electronics, Texas, USA |
| CO2 concentration | 3.5 m | LI-7500, LI-COR, USA |
Other
| Soil respiration | - |
| Photosynthesis | - |
| Ecological investigation | LAI (Li3000A, Li-COR, USA) |
Observation Period and Data Availability
| Measurement Period | From May 2006 to present |
|---|---|
| Measurement Frequency | Continuous |
| Data Availability | N/A |
Contact
Shiping Chen (spche [at] nibcas.ac.cn)
Institute of Botany, the Chinese Academy of Sciences20 Nanxincun, Xiangshan, Haidian District, Beijing 100093, P. R. ChinaTel:
+86-10- 62836279; Fax: +86-10-62599059
[Vegetation survey] Ping Zhang (zp [at]ibcas.ac.cn)
Institute of Botany, the Chinese Academy of Sciences20 Nanxincun, Xiangshan, Haidian District, Beijing 100093, P. R. China
Infrastructure
Tower, Solar Power, Facility for Accommodation Available.
Research Fund
The equipments of tower were funded by Institute of Botany, CAS; The maintenance of tower was partly supported by "100 Talents" project of CAS to Dr. Guanghui Lin and National Aeronautics and Space Administration (NASA) Grant (NEWS 2004 NRA: NN-H-04-Z-YS-005-N) of the Land-Cover / Land-Use Program
Calibration Information
Open-path analyzers were calibrated twice per year with standard CO2 gases and a dew point generator (LI610, LI-COR).
