OM2: Farm field in Osaka Metropolitan University
General site details
| Site name | Farm field in Osaka Metropolitan University |
|---|---|
| AsiaFlux site code | OM2 |
| Location | Sakai, Osaka, Japan |
| Position | 34°32'32.83"N, 135°30'29.62"E |
| Elevation | 30 m above sea level |
| Slope | 0 deg |
| Terrain type | Flat |
| Area | 0.31 ha |
| Fetch | 50 m |
| Climate | Warm temperature (Cfa) |
| Mean annual air temperature | 15.6℃ |
| Mean annual precipitation | 1206.9 mm |
| Vegetation type | Weed grassed |
| Dominant Species (Overstory) | - |
| Dominant Species (Understory) | Paspalum dilatatum, Setaria viridis, Eleusine indica, Bromus japonicus, Kyllinga brevifolia, Cyperus polystachyos, Juncus decipiens, Commelina communis, Solidago canadensis, Bidens Pilosa, Lactuca indica, Vicia villosa, Runmex japonicus, Persicaria longiseta, Ranunculus cantoniensis, Achyranthes bidentata, Oenanthe javanica |
| Canopy height | Several tens of centimeters |
| Age | Less than one year |
| LAI | 0 ~ 5 |
| Soil type | pseudo-gray soil |
Observation
Eddy Covariance method (CO2)
| System | Open-path eddy covariance |
|---|---|
| Wind speed | Sonic anemometer (81000RE, R. M. Young) |
| Air temperature | Sonic anemometer (81000RE, R. M. Young) |
| Water vapor | Open-path CO2/H2O analyzer (LI-7500, Li-Cor) |
| CO2 | Open-path CO2/H2O analyzer (LI-7500, Li-Cor) |
| Measurement height | 1.65 m |
| Sampling frequency | 10 Hz |
| Averaging time | 30 minutes |
| Data logger | CR1000 (Campbell Scientific Inc.) |
| Data storage | CF card |
| Original data | Raw data |
Meteorology
| Observation items | Levels/Depth | Instrument |
|---|---|---|
| Global solar radiation (incoming) | 1 m | Radiometer (SR05-A1, Hukseflux) |
| Global solar radiation (outgoing) | 1 m | Quantum sensor (ML-01, EKO) |
| Long-wave radiation (incoming) | - | - |
| Long-wave radiation (outgoing) | - | - |
| Net radiation | 1 m | Net Radiometer (NR LITE2, Kipp&Zonen) |
| PPFD (incoming) | - | - |
| PPFD (outgoing) | - | - |
| Direct/diffuse radiation | - | - |
| Direct/diffuse PPFD | - | - |
| Air temperature | 1.5 m | Platinum resistance thermometer and capacitive (HMP50, Vaisala) |
| Humidity | 1.5 m | Platinum resistance thermometer and capacitive (HMP50, Vaisala) |
| Soil temperature | 0, 0.05, 0.1, 0.2, 0.3, 0.4 m | Thermocouples |
| Soil heat flux | 0.05 m | Heat flux plate (HFP01SC, Hukseflux) |
| Soil water content | 0.05, 0.1, 0.2 m | TDR sensor (CS616, Campbell Scientific Inc.) |
| Wind speed | 1.65 m | Sonic anemometer (81000RE, R. M. Young) |
| Wind direction | 1.65 m | Sonic anemometer (81000RE, R. M. Young) |
| Barometric pressure | - | - |
| Precipitation | - | - |
| CO2 concentration | 1.65 m | Open-path CO2/H2O analyzer (LI-7500, Li-Cor) |
| Transmitted shortwave radiation | 0 m | Quantum sensor (ML-01, EKO) |
| Canopy temperature | 1 m | Radiation thermometer (IT-405N, Horiba) |
Other
| Phenology | Phenological Camera (TLC2000, Brinno) |
| LAI | Twice a month using a plant canopy analyzer (LAI-2000) |
Observation Period and Data Availability
| Measurement Period | April 2022 to present |
|---|---|
| Measurement Frequency | Continuous |
| Data Availability | - |
Contact
Masahito Ueyama (mueyama[at]omu.ac.jp)
Osaka Metropolitan University
Graduate School of Agriculture
1-1 Gakuencho, Naka-ku, Sakai, Osaka 599-8531, JAPAN
Phone: +81-72-254-9432
Infrastructure
Pole tower, Electrical power (AC)
Calibration Information
Open-path analyzers were calibrated approximately twice a year with standard CO2 gases a dew point generator (LI610, LI-COR) .
